Scientific Micro Molder Model:
SMMG7003B COLOR PLAQUE MOLDING MACHINE |
Samples of parts made |
|
Mold Height adjustment shown with
guard removed
Plaques showing color transition |
|
|
Machine Specifications: |
Feeding Screw Speed |
1-60rpm(max. to 100rpm,
however the torque decreases to 50% gradually after 60 rpm) |
|
Opening Stroke |
70mm(exclude the mold part)
Platen daylight without mold, approx 150mm |
|
Injection Force |
1800kg |
|
Mold Clamp Force |
6 Ton, air cylinder toggle clamp |
|
Max. Operating Temperature |
Zones 1,2,3 - 360 degrees C., note: zone 1 is
at end of barrel + nozzle heat setting % |
|
Temperature Accuracy |
+/- .5 degrees C, (After temperature has
reached constant state) |
|
Inj. Screw Diameter |
20mm, 16:1 L/D Servo Motor Drive |
|
Shot Weight |
30gm - depending on material melted weight,
minimum approx .1gm (depending on mat'l & tooling) |
|
Power Supply Required |
Single Phase 220V/1/50hz, or 60hz, 2.3Kw, 10A |
|
Tie Bar Spacing |
280×186mm
(center distance) |
|
Mold Plate Size |
360mm (L)*90mm (W) *72mm (H) |
|
Die Ring O.D. |
50mm |
|
Machine Dimensions |
(L×W×H)
1700mm, 500mm, 1350mm |
|
Electrical Brand |
PLC/HMI - Delta, SSRelay - Omron |
|
Shipping Crate Size |
1750mm X 720mm X 1400mm - Weight approx. 450kg |
|
Air Compressor is supplied by
customer - Recommend 20 gallon reservoir unit - low noise |
|
